Submersible pump Pedrollo 4SR4/15 F-PD, 1.5 kW


For water supply tasks from deep wells with increased demands for head and flow rate, the Pedrollo 4SR4/15 F-PD submersible electric pump is the ideal solution. This powerful pump, with a 1.5 kW motor, is capable of delivering clean water from depths of up to 114 meters, making it indispensable for large private homes, commercial facilities, as well as for agricultural use and industrial needs. It effectively handles tasks such as irrigating vast areas, operating powerful washing equipment, maintaining pressure in large water supply systems, and use in fire-fighting systems.
The Pedrollo 4SR4/15 F-PD model belongs to the 4SR series, which has proven itself due to its high efficiency (COP) and exceptional reliability. The pump is designed for pumping clean water with a sand content of no more than 150 g/m³ and requires installation in wells with a diameter of at least 4 inches (100 mm).
Technical Specifications and Key Features:
Optimal Submersion: To ensure uninterrupted operation, the electric pump must be fully submerged in water, at a depth of at least 50 cm from the surface and no less than 1 meter from the bottom of the well.
Installation Flexibility: The pump can be installed in both vertical and horizontal positions. For vertical installation in a well, for additional safety, it is recommended to use a stainless steel or nylon rope, secured through the specially provided holes in the discharge body.
Liquid Parameters: Pumping clean water with a temperature of up to +30°C is permitted. The maximum content of suspended solid particles is 150 g/m³.
Durability and Lifespan: High quality materials and assembly guarantee a long service life for the pump. Up to 20 starts per hour allows the pump to be used in systems with frequent switching on and off.
Wide Range of Applications: In addition to domestic and municipal use, the pump is successfully applied in industry, for automatic water supply in conjunction with automatic pressure maintenance units, for irrigation systems, for washing equipment, for pressure boosting, and in fire safety systems.
By choosing the Pedrollo 4SR4/15 F-PD, you get reliable, powerful, and highly efficient equipment capable of ensuring stable water supply for the most demanding facilities for many years to come.
Maximum pumping height, m: | 120 |
Maximum sand content in water, g/m³: | 150 |
Degree of protection: | IP68 |
Height teh, mm: | 959 |
Installation method: | Vertical |
Max. liquid temperature, °C: | +35 |
Coutry of brand: | Italy |
Connection diameter, inch: | 1 1/4 |
Weight, kg: | 16,3 |
Diameter, mm: | 98 |
Tip motor: | three-phase |
Impeller Material: | Delrin |
Body material: | INOX AISI 316 |
Water consumption, m³/h: | 6,0 |
Power, kW: | 1,5 |
Revolutions Per Minute, r/min: | 2900 |
